Galvanised · 316 Stainless
Double Sleeve Expansion Ties
About the Double Sleeve Expansion Ties
VUETRADE Double Sleeve Expansion Ties are rod ties for vertical expansion joints: a sleeve on each end is laid into either side of the joint so the wall can move. 5.5mm bar for a control gap of up to 50mm. Galvanised (290mm, metal sleeves, durability class R2) or 316 stainless (324mm, polypropylene sleeves, class R4), cartons of 50. VUETRADE states they comply with AS/NZS 2699 and AS 3700.
Features
- Sliding rod tie for vertical expansion joints, control gap up to 50mm (VUETRADE)
- 5.5mm bar
- Galvanised: 290mm, G300 Z600, metal sleeves, durability class R2 (AS/NZS 2699.1:2020)
- 316 stainless: 324mm, polypropylene sleeves, durability class R4
- Galvanised (R2): 10km or more from breaking surf and 1km or more from a sheltered coast, and not in contact with fresh water or frequent non-saline wetting and drying (VUETRADE area chart)
- 316 (R4) for sites within 1km of breaking surf or 100m of a sheltered coast (VUETRADE)
- AS/NZS 2699 and AS 3700 (VUETRADE)
- Check local rules on stainless ties (VUETRADE)
Applications
- Vertical expansion joints in brick and block walls
- Coastal masonry with the 316 version
Double Sleeve Expansion Ties: sizes and finishes we supply
2 lines by finish. Pick one above for its product code and pack sizes.
| Finish | Sizes | Lines |
|---|---|---|
| Galvanised | - | 1 |
| 316 Stainless | - | 1 |
Need them in bulk?
Add the sizes you need to your quote, or send us your list and we’ll price the lot and supply it with the rest of your order. Allmat supplies Double Sleeve Expansion Ties across Adelaide and South Australia. Order ahead on 1300 03 03 63.
Browse all masonry ties
